Quantum Surface Pond Aerator, 5HP–20HP floating aerator for aquaculture and wastewater
Quantum Surface Pond Aerator, 5HP–20HP floating aerator for aquaculture and wastewater

Quantum - Pond Surface Aerator Fountain for Aquaculture / Water Treatment | 5HP-20HP

Industrial-grade aeration, all-season.

$7,795.00
Horse Power: 5 HP
Voltage: 230v
Power Phase: Single (Most Common)

Why You'll Love It

  • Up to 15 lbs O₂/HP/hr
  • Ice- and storm-proof build
  • 3,400 GPM high-volume flow

Specifications

  • Horsepower: 5 HP Flow Rate: Up to 2,700 GPM
  • Oxygen Transfer: Up to 15 lbs O₂/HP/hr
  • Motor: Franklin Electric stainless submersible, UL778 recognized
  • Cooling/Lubrication: Water-cooled & water-lubricated
  • Seals: Silicone carbide mechanical seals
  • Propeller: Balanced 316 stainless steel
  • Diffuser: High-efficiency directional design
  • Floatation: 36” polyethylene base, 4” styrene foam-filled
  • Cord: 100’ standard, 50’ increments available Minimum Operating Depth: 36”
  • Voltage: 230V, single-phase
  • Construction: Made in the USA

Description

Overview ▾

Variant SKU: 94SA5023016

Quantum Surface Pond Aerator | 5HP–20HP

The Aquarian Quantum Surface Aerator is engineered for high-performance aeration in aquaculture, wastewater treatment, and large pond or lake applications. Designed to create a continuous air/water interface while mixing and suspending solids, this system dramatically improves oxygen transfer and water circulation.

With pumping rates from 3,400 to 8,300 GPM and oxygen transfer up to 50 lbs O₂/hr, the Quantum series delivers powerful, reliable aeration for demanding environments.

Key Features ▾
  • High Volume Pumping: 3,400–8,300 GPM depending on horsepower.
  • Exceptional Oxygen Transfer: Up to 50 lbs O₂ per hour.
  • Omni-Directional Diffuser: Redirects water outward at right angles to the surface.
  • Maximum Water Mixing: Keeps degradable solids in suspension.
  • All-Season Stability: Over 95% of unit weight remains below surface to prevent capsizing.
  • Commercial & Industrial Ready: Built for demanding aquaculture and treatment environments.
Performance Specifications ▾
<
Model 5HP 7.5HP 10HP 15HP 20HP
Voltage 230V 1PH / 230/460V 3PH 230/460V 3PH 230/460V 3PH 230/460V 3PH 230/460V 3PH
Oxygen Transfer (lbs O₂/hr) 15.0 23.0 30.0 45.0 50.0

Vendor: Outdoor Water Solutions

Type: Electric Pond Aerator

SKU: 94SA5023016
Quantum Surface Pond Aerator, 5HP–20HP floating aerator for aquaculture and wastewater

Quantum - Pond Surface Aerator Fountain for Aquaculture / Water Treatment | 5HP-20HP

$7,795.00

Frequently Asked Questions

Is this right for smaller ponds?

Probably not-it’s designed for large-scale, high-volume water systems like municipal lagoons, industrial ponds, and big agricultural applications.

Can it run in freezing conditions?

Yes-its submerged design and low spray trajectory prevent icing and maintain operation all winter.

What upkeep is required?

Minimal-inspect cord and mooring seasonally; the sealed motor and bearings are built for long-term reliability.

Is this right for smaller ponds?

Probably not-it’s designed for large-scale, high-volume water systems like municipal lagoons, industrial ponds, and big agricultural applications.
